2.5″ SATA SSD 3TS5-P 256GB

3TS5-P is Innodiskâs first product series supported 3D NAND flash. Innodisk 2.5" SATA SSD 3TS5-P is characterized by L³ architecture and RAID engine with the latest SATA III (6.0GHz) ID204 controller. Innodiskâs exclusive L³ architecture is L² architecture multiplied LDPC (Low Density Parity Check). L² (Long Life) architecture is a 4K mapping algorithm that reduces WAF and features a real-time wear leveling algorithm to provide high performance and prolong lifespan. Innodisk 2.5" SATA SSD 3TS5-P is equipped RAID engine to offer additional level of data protection for exceptional reliability.

Enquire Datasheet

Part Number:

DSS25-B56D21ECAQH(P)

Features

2.5" SATA III solution for industrial field
DWPD equals to 2.0
High IOPS with 3D NAND solution
L³ architecture extends lifespan
RAID Protection
iData Guard for abnormal power failure
Built-in thermal sensor
iCell technology for data protection (optional)
iSMART disk health monitoring

Specifications

Max Read Speed: 560

Max Write Speed: 490

Max Power Consumption: 6.15 W (5V x 1230 mA )

Max Channels: 4

Thermal Sensors: Y

External Dram Buffer: Y

iCell: Y

S.M.A.R.T: Y

ATA Security: Y

Dimensions: 69.85 x 100.10 x 6.9

Vibration: 20G@7~2000Hz

Shock: 1500G@0.5ms

MTBF: >3 million hours

Flash P/E Cycle Limit: 10,000

Storage Temperature: -55°C ~ +95°C
