EDC 1SE2 Horizontal 64GB

The Innodisk Embedded DISK CARD 1SE2 (EDC 1SE2) products provide high capacity solid-state flash memory that electrically complies with the Personal Computer Memory Card International Association ATA standard. Innodisk Embedded DISK CARD 1SE2 (EDC 1SE2) is embedded solid-state data storage systems for industrial work place. Embedded DISK CARD 1SE2 (EDC 1SE2) features an extremely light weight, reliable, low-profile form factor. Embedded DISK CARD 1SE2 (EDC 1SE2) supports advanced PIO (0-6), Multi Word DMA (0-4), Ultra DMA (0-6) transfer modes, multi-sector transfers, and LBA addressing.

Enquire Datasheet

Part Number:

DEE4X-64GD53AC1DB

Features

iSMART disk health monitoring
Intelligent error recovery system
Excellent data transfer speed
Write protection security
Enhanced power cycling management

Specifications

Max Read Speed: 110

Max Write Speed: 75

Max Power Consumption: 0.76W(3.3V x 230mA)

Max Channels: 2

H/W Protect: Optional

S.M.A.R.T: Y

ATA Security: Y

Dimensions: 48 x 32.6 x 7.3

Vibration: 20G@7~2000Hz

Shock: 1500G@0.5ms

MTBF: >3 million hours

Flash P/E Cycle Limit: 60,000

Storage Temperature: -55°C ~ +95°C
