mSATA mini 3SE 1GB

Innodisk mSATA mini 3SE is designed as the standard Mini PCIe form factor with SATA interface, and supports SATA III standard (6.0Gb/s) with excellent performance. The form factor refers to the MO-300 / MO-300B specification which established by JEDEC. Regarding of mechanical interference, InnoDisk mSATA mini 3ME absolutely replaces the traditional hard disk and makes personal computer, in any field, smaller and easier. Innodisk mSATA mini 3SE effectively reduces the booting time of operation system and the power consumption is less than hard disk drive (HDD), and complies with ATA protocol, no additional drives are required, and can be configured as a boot device or data storage device.

Enquire Datasheet

Part Number:

DEMSM-01GD07AC2SB

Features

Specifications

Max Read Speed: 300

Max Write Speed: 130

Max Power Consumption: 0.5 W (3.3V x 150 mA )

Max Channels: 2

Thermal Sensors: Wide Temp. only

S.M.A.R.T: Y

ATA Security: Y

Dimensions: 30.0 x 26.8 x 3.7

Vibration: 20G@7~2000Hz

Shock: 1500G@0.5ms

MTBF: >3 million hours

Flash P/E Cycle Limit: 60,000

Storage Temperature: -55°C ~ +95°C

SATA 6Gb/S interface
iSMART disk health monitoring
Intelligent error recovery system
Excellent data transfer speed
Zero mechanical interference
Anti-vibration mechanical design
JEDEC standard MO-300 dimension
