SATA Slim 3MV2-P 8GB

InnoREC is innodiskâs proprietary flash feature set designed specifically for surveillance applications. Through the smart integration of firmware and hardware, the speed and performance required by modern surveillance solutions is fully met. SATA Slim 3MV2-P products provide high capacity flash memory Solid State Drive (SSD) that electrically complies with Serial ATA (SATA) standard. It supports SATA III standard (6.0GHz) with high performance and supports several features, including REC line, iData Guard, Quick Erase, Thermal sensor, and S.M.A.R.T.

Enquire Datasheet

Part Number:

DVSLM-08GD81BW1SC

Features

Specifications

Max Read Speed: 140

Max Write Speed: 25

Max Power Consumption: 2.6W (5V x 520 mA )

Max Channels: 4

Thermal Sensors: Y

External Dram Buffer: Y

H/W Protect: Optional

S.M.A.R.T: Y

ATA Security: Y

Dimensions: 54.0 X 39.0 X 4.0

Vibration: 20G@7~2000Hz

Shock: 1500G@0.5ms

MTBF: >3 million hours

Flash P/E Cycle Limit: 3,000

Storage Temperature: -55°C ~ +95°C

SATA III soultion for industrial field
High IOPS solution
iData Guard protection
iSMART disk health monitoring
Intelligent error recovery system
Excellent data transfer speed
Zero mechanical interference
Compatible with JEDEC MO-297 standard
