ServerDOMV 3ME3 128GB

Innodisk ServerDOMâ¢ is dedicated to the further of server design. By using ServerDOMâ¢ as a boot drive, there is more space for the hot-swappable data storage devices. Innodisk ServerDOMâ¢ is designed with SATA III interface and complaint with server grade stranded, such as supporting for Intel® RSTe. Furthermore, with our excellent development team, we are able to provide customized services to fulfill different inquires; H/W design or software integration, such as IPMI.

Enquire Datasheet

Part Number:

DESNV-A28D08BCAQC

Features

Bootable and compatible with all OS
Better reliability and MTBF than HDD
Small dimension for Blade or 1U servers
Compatible with Intel® RSTe
Cost effective storage solution
Optional SATA Pin 7 VCC to enhance reliability and save space
Customizable for IPMI
Unexpected power loss protection

Specifications

Max Read Speed: 480

Max Write Speed: 150

Max Power Consumption: 1.5 W

Max Channels: 4

S.M.A.R.T: Y

ATA Security: Y

Dimensions: 20.2 x 30.7 x 8.7

Vibration: 20G@7~2000Hz

Shock: 1500G@0.5ms

MTBF: >3 million hours

Flash P/E Cycle Limit: 3,000

Storage Temperature: -55°C ~ +95°C

Bootable and compatible with all OS
Better reliability and MTBF than HDD
Small dimension for Blade or 1U servers
Compatible with Intel® RSTe
Cost effective storage solution
Optional SATA Pin 7 VCC to enhance reliability and save space
Customizable for IPMI
Unexpected power loss protection
