IDEDOM SSD TS1GPTM520 1GB

1GB 40P IDE FLASH MODULE, SLC (Vertical)

Transcend’s 40-pin PATA PTM520 Flash Modules can be inserted directly to a system motherboard via any PATA (IDE) interface to replace conventional 3.5″ hard disk drives. Ideal for use as bootable drives, the 40-pin PATA PTM520 Flash Module is an easy solution for integrating SSD storage technology into legacy PC-based systems.

Enquire Datasheet

Part Number:

TS1GPTM520

Features

Firmware Features

Based on PIO Mode 0~4
Based on Ultra DMA Mode 0~5
Built-in ECC (Error Correction Code) functionality
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Security Command

Hardware Features

Compliant with RoHS 2.0 standards
SLC NAND flash

Specifications

Max Read Speed: 39 MB/s

Max Write Speed: 42 MB/s

Max Power Consumption: 0.9 watt(s)

ATA Security: YES

Flash P/E Cycle Limit: 50k

Firmware Features

Based on PIO Mode 0~4
Based on Ultra DMA Mode 0~5
Built-in ECC (Error Correction Code) functionality
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Security Command

Hardware Features

Compliant with RoHS 2.0 standards
SLC NAND flash

Max Read Speed: 39 MB/s

Max Write Speed: 42 MB/s

Max Power Consumption: 0.9 watt(s)

ATA Security: YES

Flash P/E Cycle Limit: 50k
