M.2 2280 MTE712P 512GB

512GB, M.2 2280, PCIe Gen4x4, M-Key, 3D TLC BiCS5, PE: 3K, 4CH, wide temp., TCG OPAL, eDrive,PLP

Transcend’s M.2 SSD MTE712P is a Power Loss Protection (PLP) SSD. During unexpected power outages, the built-in tantalum capacitor provides power to the controller and DRAM cache, ensuring data integrity and storage reliability. The MTE712P also complies with the TCG (Trusted Computing Group) Opal 2.0 standards. Data is protected using the hardware-based AES 256-bit encryption and LBA (Logical Block Address) sector-specific permissions.

Available in 256GB, 512GB, 1TB, 2TB.

Enquire Datasheet

Part Number:

TS512GMTE712P

Features

Firmware Features

Supports NVM command
Dynamic thermal throttling
Built-in LDPC ECC (Error Correction Code) functionality
Advanced Global Wear-Leveling and Block management for reliability
Advanced Garbage Collection
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
TRIM command for better performance
NCQ command for better performance
Full drive encryption with Advanced Encryption Standard (AES)
Compliant with TCG Opal specifications and IEEE 1667 standards

Hardware Features

Compliant with RoHS 2.0 standards
Compliant with NVM Express specification 1.4
Compliant with PCI Express specification 4.0
Space-saving M.2 form factor (80mm) – ideal for mobile computing devices
PCIe Gen 4 x4 interface
DDR4 DRAM Cache embedded
High-quality 3D NAND flash
Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
Key components fortified by default with Corner Bond technology
30µ” PCB gold finger
Anti-sulfur technology implemented to prevent sulfurization in the environment
Power Loss Protection (PLP) to prevent data loss in the event of sudden power outage
Promised operational reliability in a wide temperature range (from -40°C to 85°C)

Specifications

Max Read Speed: Up to 3,800 MB/s

Max Write Speed: Up to 3,100 MB/s

Max Power Consumption: 4 watts

Dimensions: 80 mm x 22 mm x 3.88 mm (3.15" x 0.87" x 0.15")

MTBF: 3,000,000 hour(s)

Storage Temperature: Wide Temp. -40°C (-40°F) to 85°C (185°F)

Interface: NVMe PCIe Gen4 x4
