M.2 SSD MTE352T 256GB

256GB, M.2 2230, PCIe Gen3x2, B+M Key, 3D TLC BiCS4, DRAM-less, PE: 3K

Transcend’s single-sided MTE352T M.2 SSD features the PCI Express (PCIe) Gen 3 x2 interface and is compatible with NVM Express (NVMe) 1.3 specifications to achieve never-before-seen transfer speeds. The MTE352T features state-of-the-art 3D NAND technology, which allows 96 layers of 3D NAND flash chips to be vertically stacked. Compared to 3D NAND at 64 layers, this density breakthrough greatly improves storage efficiency. Applied with 30µ” gold finger PCB and Corner Bond technology, the MTE352T is fully tested in-house to guarantee reliability, boasting an endurance rating of 3K Program/Erase cycles and an extended operating temperature ranging from -20℃~75℃.

Enquire Datasheet

Part Number:

TS256GMTE352T

Features

Firmware Features

Supports NVM command
SLC caching technology
Dynamic thermal throttling
Built-in LDPC ECC (Error Correction Code) functionality
Advanced Global Wear-Leveling and Block management for reliability
Advanced Garbage Collection
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Full drive encryption with Advanced Encryption Standard (AES) (optional)

Hardware Features

Compliant with RoHS 2.0 standards
Compliant with NVM Express specification 1.3
Compliant with PCI Express specification 3.1
Single-sided to fit perfectly in small form factor devices
Space-saving M.2 form factor (30mm) – ideal for mobile computing devices
PCIe Gen 3 x2 interface
Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
Key components fortified by default with Corner Bond technology
30µ” PCB gold finger
Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
Promised operational reliability in an extended temperature range (from -20°C to 75°C)
Supports Transcend Scope Pro software

Specifications

Max Read Speed: 1700 MB/s

Max Write Speed: 1000 MB/s

Max Power Consumption: 3.2 W

Thermal Sensors: Y

External Dram Buffer: N

H/W Protect: N

S.M.A.R.T: Y

DEVSLP Mode: N

Dimensions: 22, 30, 2.38

Vibration: Y

Shock: Y

MTBF: 3,000,000

Flash P/E Cycle Limit: 3K

Storage Temperature: -55c to 85c
