M.2 SSD MTE5601 80GB

Transcend’s M.2 SSD MTE560I features a PCI Express (PCIe) Gen4 x4 interface, 112 layers of 3D NAND flash, and SLC Mode technology, delivering high sustained speeds and SLC-grade durability. Its built-in DRAM cache enables fast random read and write speeds, and improves drive endurance. In addition, the 30µ” gold finger PCB, Corner Bond technology, and anti-sulfur resistors guarantee its reliability in harsh conditions. Transcend’s MTE560I is also 100% chamber tested in-house for wide operating temperatures of -40℃~85℃.

Additionally, the MTE560I is a self-encrypting drive (SED) that complies with the TCG (Trusted Computing Group) 2.0 standards. Data is protected using the hardware-based AES 256-bit encryption and LBA (Logical Block Address) sector-specific permissions.

Enquire Datasheet

Part Number:

TS80GMTE560I

Features

Firmware Features

Supports NVM command
Dynamic thermal throttling
Built-in LDPC ECC (Error Correction Code) functionality
Advanced Global Wear-Leveling and Block management for reliability
Advanced Garbage Collection
Static Data Refresh
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
TRIM command for better performance
NCQ command for better performance
Full drive encryption with Advanced Encryption Standard (AES)
Compliant with TCG Opal specifications and IEEE 1667 standards

Hardware Features

Compliant with RoHS 2.0 standards
Compliant with NVM Express specification 1.4
Compliant with PCI Express specification 4.0
Space-saving M.2 form factor (80mm) – ideal for mobile computing devices
PCIe Gen 4 x4 interface
DDR4 DRAM Cache embedded
High-quality 3D NAND flash and SLC mode for exceptional endurance and reliability
Key components fortified by default with Corner Bond technology
30µ” PCB gold finger
Anti-sulfur technology implemented to prevent sulfurization in the environment
Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
Promised operational reliability in a wide temperature range (from -40°C to 85°C)
Supports Transcend Scope Pro software

Specifications

Interface: NVMe PCIe Gen4 x4

Firmware Features

Supports NVM command
Dynamic thermal throttling
Built-in LDPC ECC (Error Correction Code) functionality
Advanced Global Wear-Leveling and Block management for reliability
Advanced Garbage Collection
Static Data Refresh
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
TRIM command for better performance
NCQ command for better performance
Full drive encryption with Advanced Encryption Standard (AES)
Compliant with TCG Opal specifications and IEEE 1667 standards

Hardware Features

Compliant with RoHS 2.0 standards
Compliant with NVM Express specification 1.4
Compliant with PCI Express specification 4.0
Space-saving M.2 form factor (80mm) – ideal for mobile computing devices
PCIe Gen 4 x4 interface
DDR4 DRAM Cache embedded
High-quality 3D NAND flash and SLC mode for exceptional endurance and reliability
Key components fortified by default with Corner Bond technology
30µ” PCB gold finger
Anti-sulfur technology implemented to prevent sulfurization in the environment
Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
Promised operational reliability in a wide temperature range (from -40°C to 85°C)
Supports Transcend Scope Pro software

Interface: NVMe PCIe Gen4 x4
