SDC460T 512GB

512GB SD Card A1 U1/V10, 3D TLC BiCS5

Utilizing top-quality 3D NAND flash and rated to endure 3K P/E cycles, Transcend’s SDXC 460T memory cards combine the advantages of high performance and exceptional endurance at an affordable price, making them ideal for demanding industrial applications such as POS terminals as well as portable devices equipped with an SD memory card slot.

Enquire Datasheet

Part Number:

TS512GSDC460T

Features

Firmware Features

Built-in LDPC ECC (Error Correction Code) functionality
Early Move
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Wear-Leveling
Supports password protection and secure erase via Scope Pro

Hardware Features

Compliant with RoHS 2.0 standards
Electrostatic protection (ESD IEC 61000-4-2)
Compliant with SD specification 6.1
Compliant with UHS-I
Compliant with Video Speed Class 30 (V30)
Compliant with Application Performance Class 2 (A2)
Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
Supports Transcend Scope Pro software

*Scope Pro is available on Windows OS only when the RDF5 is used with the SD/microSD cards.
*Transcend’s SDXC 460T 64GB cards meet UHS-I Speed Class 1 (U1), Video Speed Class 10 (V10), and Application Performance Class 1 (A1) standards.

Specifications

Max Read Speed: Up to 100 MB/s

Max Write Speed: Up to 85 MB/s

Dimensions: 24 mm x 32 mm x 2.1 mm (0.94" x 1.26" x 0.08")

Storage Temperature: -40°C (-40°F) ~ 85°C (185°F)

Firmware Features

Built-in LDPC ECC (Error Correction Code) functionality
Early Move
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Wear-Leveling
Supports password protection and secure erase via Scope Pro

Hardware Features

Compliant with RoHS 2.0 standards
Electrostatic protection (ESD IEC 61000-4-2)
Compliant with SD specification 6.1
Compliant with UHS-I
Compliant with Video Speed Class 30 (V30)
Compliant with Application Performance Class 2 (A2)
Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
Supports Transcend Scope Pro software

Max Read Speed: Up to 100 MB/s

Max Write Speed: Up to 85 MB/s

Dimensions: 24 mm x 32 mm x 2.1 mm (0.94" x 1.26" x 0.08")

Storage Temperature: -40°C (-40°F) ~ 85°C (185°F)
